Place of Origin:
China
Brand Name:
TONGDA
Certification:
ISO,CE
Model Number:
TD-50
Document:
Wholesale Price 25kg 50kg Fertilizer Bagging Equipment/ Pellet Packing Machine
Package Machine Description: Our packaging machine is widely used in feed, fertilizer, grain, chemical industry, building materials, starch, food, rubber and plastics, hardware, minerals,covering more than 20 industries, more than 3,000 kinds of materials.
Technical characteristics:
1. PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting , finished in one operation.
2. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
3. Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
4. External film releasing mechanism: simpler and easier installation of packing film.
5. Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple .
6. Close down type mechanism , defending powder into inside of machine.
| Model | Weighing Range (KG) | Packaging Accuracy | Packaging Rate | Microscopic Index Value (kg) | Working Environment | ||
| Index | Per Time | Average | Single Weighing | Temperature | Relative Humidity | ||
| TD-50 | 25-50 | <±0.2% | <±0.1% | 300-400 | 0.01 | -10~40°C | <95% |
| Special model | ≥100 | Customized processing according to user needs | |||||
| Remarks | Sewing machine, automatic counting, infrared thread trimming, edge removal machine, you can choose according to customer requirements | ||||||
Functional features of bucket metering packaging machine:
1. Equip with safety protection and meet the requirements of enterprise safety management.
2. The bucket metering packaging machine can be selected from all stainless steel models and carbon steel plastic spraying models.
3. The touch screen can store the packaging process parameters of a variety of different products, which can be used at any time when changing products without resetting.
4. The bucket metering packaging machine and metering configuration can automatically complete the whole packaging process of metering, feeding, filling and finished product transportation, and automatically complete counting.
Package Machine Working Process: Manual giving the empty bags-Automatic bag clamp-Automatic feeding-Automatic weighing-Automatic discharge-Automatic bag release-Bag conveying to the closed machine-Bag closed by sewing or heat sealing.
FAQ:
1. Are you trading company or manufacturer ?
We are a manufacturer with a history over 40 years and have realized one-stop service for design, manufacture, installation, debugging and technical training.
2. How long is the delivery time?
For standard machines or Components, it would be 5-10 days; For non-standard machines and customized machines according to clients specific requirements, it would be appointment time.
3. Do you arrange shipment for the machines?
Yes, we will do that. For FOB or CIF price, we will arrange shipment for you. For EXW price, we will assist you in arranging shipment.
4. How about your product after-sales service?
Normally we provide video and written technical support. If necessary, our engineers can also provide on-site service. Our product accessories can be selected according to the actual needs of the customer to choose the most appropriate way to deliver.
5. What kinds of certificate you have?
ISO 9001: 2015 SGS and we can make other certificates according to customers' detailed requirements.
6. How to guarantee the quality and operation before loading?
We have our own quality control department and have advance quality control stystem while from raw materials to finished products. All the machines and production lines shall be 100% checked and tested before delivery.
